Magnetic modification of lanthanide-based upconversion nanocrystals for fingerprint information recognition

1.   Introduction

When the finger touches the surface of the object, the distribution pattern of skin ridges and grooves, combined with secreted sweat, oily substances and foreign contaminants, leaves an impression of the unique fingerprint pattern^[1-3]. Owing to its invisibility to the naked eye, the pattern is known as a latent fingerprint^[4,5]. Nonetheless, such latent fingerprints can be recognized through proper chemical or physical treatment. For instance, aluminum flake powder, magnetic powder, iron flake powder and fluorescent powder are widely used for fingerprint enhancement in practical fingerprint detection technologies^[6,7]. Among them, the magnetic fluorescent composite structure is one of the ideal alternatives for enhancing the visibility of latent fingerprints because magnetism can facilitate the nondestructive development of latent fingerprints and fluorescence can increase the contrast of fingerprint patterns^[8]. Considering that the photoreceptors in the commonly used camera exhibit the highest quantum efficiency in the range of 500–700 nm, lanthanide upconversion nanocrystals (e.g., NaGdF₄:Yb,Er) with luminescence regions in the range of 507–533 nm, 533–568 nm and 637–683 nm are regarded as ideal luminescent material candidates. Ferroferric oxide (Fe₃O₄) is a well-observed compound with strong magnetism. Taken together, the composite of NaGdF₄:Yb,Er and Fe₃O₄ is highly anticipated as a good latent fingerprint recognition probe with high sensitivity.

Nevertheless, the synthesis of NaGdF₄:Yb,Er-Fe₃O₄ nanocomposites faces reduced stability due to the high temperature during synthesis (350 °C)^[9]. The encapsulation approach (i.e., coating method) in an aqueous phase system is commonly used according to previous reports; that is, NaGdF₄:Yb,Er and Fe₃O₄ are simultaneously enclosed in another shell layer^[10,11]. Unfortunately, this method still confronts the dilemma of ensuring that both materials can be well encased in the same shell structure. Another alternative option is to create Fe₃O₄ nanostructures first as the core and then in situ grow NaGdF₄ shell layers^[12]. However, high temperature is typically required during the synthesis of NaGdF₄, which is adverse to the magnetic properties of the Fe₃O₄ core. In this regard, it is of high urgency to develop a synthesis method that can reduce the impact on the magnetic and luminescent functional components of composite materials.

In this work, we demonstrate a simple ligand-linked method to synthesize NaGdF₄:Yb,Er-Fe₃O₄ nanocomposites based on NaGdF₄:Yb,Er nanocrystals doped with luminescent lanthanide ions^[13]. Taking ethyl orthosilicate (TEOS) as the ligand in n-propanol solvent, we can assemble NaGdF₄:Yb,Er and Fe₃O₄ as nanocomposites with good dispersion. Specifically, the upconversion luminescence of NaGdF₄:Yb, Er and magnetism of Fe₃O₄ can be well balanced. As a result, the as-prepared NaGdF₄:Yb,Er-Fe₃O₄ composite exhibits high contrast and high resolution in the latent fingerprint visualization process.

2.   Materials and methods

Synthesis of NaGdF₄:Yb,Er. 1600 μL of gadolinium trichloride solution (1 mol/L), 360 μL of ytterbium trichloride solution (1 mol/L), 400 μL of erbium trichloride solution (0.1 mol/L), 26 mL of ultrapure water and 7.2 mL of sodium hydroxide solution (1 mol/L) were added into a beaker. After stirring for 1 h, the solution was centrifuged and washed three times to obtain the precipitate. The precipitate was transferred to a three-necked flask and redispersed in 16 mL ultrapure water through ultrasonication. Then, 4.2 mL of sodium hydroxide solution (1 mol/L) was added into the three-necked flask. After stirring for 10 min, 14 mL oleic acid was further introduced into the flask. The solution was then heated to 100 °C, and the heating was maintained until no bubbles were generated and the solution became clear and transparent. After the temperature was reduced to room temperature, 25.6 mL of 1-octadecene was added with stirring for 15 min. Then, 1.46 mL of trifluoroacetic acid was added with stirring for an additional 30 min. Under the sealing condition of 100 °C, the inside of the flask was evacuated to a vacuum, then under the protection of N₂, the temperature was raised to 350 °C, and the reaction was continued for 40 min. After the reaction was completed, the solution was cooled to room temperature, and the product was obtained by washing and centrifugation 5 times.

Synthesis of NaGdF₄:Yb,Er-Fe₃O₄. 30 mg of as-purchased Fe₃O₄ was dispersed in 30 mL of ethanol solution to make a suspension of 1 mg/mL for further use. Then, 72 mL of n-propanol, 72 mg of NaGdF₄ and 24 mL of Fe₃O₄ ethanol suspension were added into a 500-mL round-bottomed flask and stirred by a mechanical stirring table with a Teflon stirring bar. After dispersing for 30 min, 360 μL of NaOH solution (2 mol/L) and 60 μL of TEOS were added and stirred in an oil bath at 70 °C for 18 h in a sealed state. Finally, the obtained product was collected by centrifugation, washed with absolute ethanol and then dried in a vacuum drying oven.

3.   Results and discussion

According to previous reports^[14-16], NaGd(80%)F₄:Yb(18%),Er(2%) was synthesized as the luminescent upconversion counterpart. The characterization results (Figs. S1–S3) of the as-synthesized sample demonstrate that the upconversion material has a hexagonal morphology with an edge length of approximately 60 nm with optimized fluorescence intensity. Furthermore, using a ligand-linked approach (TEOS as a ligand), we synthesized a NaGdF₄:Yb,Er-Fe₃O₄ composite structure based on the as-synthesized NaGdF₄:Yb,Er nanocrystals with Fe₃O₄ as the magnetic counterpart. Fig. 1a depicts the accumulation of Fe₃O₄ with comparable size surrounding the original NaGdF₄:Yb,Er hexagonal nanoparticles. Energy-dispersive X-ray spectroscopy (EDS) (Fig. S3b) shows the presence of Na, Yb, Fe and other elements. Fig. 1b illustrates that the elemental mapping distributions of the F, O and Fe elements are similar, indicating that the as-obtained sample is composed of NaGdF₄:Yb,Er and Fe₃O₄. The emerging X-ray diffraction (XRD) diffraction peak (Fig. 1c) is compatible with the diffraction pattern of hexagonal NaGdF₄ (PDF#27-0699) and cubic Fe₃O₄ (PDF#99-0073), indicating that the product is highly crystalline. The infrared spectrum peaks of O–H stretching and Si–O–Si asymmetric/symmetric stretching vibration (Fig. S4) in the NaGdF₄:Yb,Er-Fe₃O₄ structure indicate the presence of TEOS ligands. These structural characterizations demonstrate that the NaGdF₄:Yb,Er-Fe₃O₄ composite is successfully prepared. The fluorescence spectra of the composite (Fig. 1d) show that the ratio between 520 nm and 540 nm is balanced compared to the bare NaGdF₄:Yb,Er, and the fluorescence property of our NaGdF₄:Yb,Er-Fe₃O₄ composite is still acceptable even if there is a significant decline. We then explored the effects of the reactant feed ratio and reaction time on the fluorescence properties of the products. Fluorescence spectra (Fig. S5 and Table S2) showed that the peak intensity was the highest when the feeding ratio was 4.5∶1 with an 18 h reaction time.

Figure  1.  (a) Transmission electron microscopy (TEM) image, (b) mapping image, (c) XRD pattern and (d) fluorescence spectra of NaGdF₄:Yb,Er-Fe₃O₄.

DownLoad: Full-Size Img PowerPoint

Reducing the sacrifice of fluorescence intensity, enhancing the saturation magnetization of the material, and seeking the relative balance of fluorescence and magnetism are conducive to the construction of fingerprint powders with excellent performance. As shown in Fig. 2, the saturation magnetization intensities of the two NaGdF₄:Yb,Er-Fe₃O₄ composite nanomaterials decrease slightly relative to that of Fe₃O₄ but still remain on the same order of magnitude. In particular, the NaGdF₄:Yb,Er-Fe₃O₄ (N∶F=4∶1) sample improved the magnetic characteristics of the upconversion material by approximately half while maintaining the fluorescence properties.

Figure  2.  Magnetic characterizations. (a–c) The hysteresis loop of (a) Fe₃O₄, (b) NaGdF₄:Yb,Er-Fe₃O₄ (t=18 h) and (c) NaGdF₄:Yb,Er-Fe₃O₄ (N∶F=4∶1). (d) Photograph of the NaGdF₄:Yb,Er-Fe₃O₄ (N∶F=4∶1) sample attracted by the magnet.

DownLoad: Full-Size Img PowerPoint

To explore the application performance of the as-synthesized NaGdF₄:Yb,Er-Fe₃O₄ composite nanomaterials for latent fingerprint detection, we carried out three classic crafts, including the powder spraying technique, residual powder adsorption and infrared excitation (Fig. S6)^[17]. The visualization of latent fingerprints mainly includes three processes: powder adhesion, blowing, and excitation. First, press the finger on the substrate to obtain invisible latent fingerprints, and then use a magnetic fingerprint brush to carry out the process of fingerprint adsorption and detachment. The above process was repeated, and excess powder was blown off to obtain visible latent fingerprints. Under the irradiation of 980 nm infrared light, we can observe the green emitting fingerprint pattern through the charge-coupled device (CCD) imaging system. The feasibility of fingerprint detection is highly dependent on the accuracy of identifying the latent fingerprint level 1, 2, and 3 features^[18], which are regarded as absolutely critical quantitative criteria in practice. The unique ridge features of fingerprints on smooth metal surfaces can be viewed and photographed using NaGdF₄:Yb,Er-Fe₃O₄ nanomaterials as photoreceptors under 980 nm infrared (IR) laser irradiation, and all three levels of fingerprint features can be clearly recognizable (Fig. 3). The primary pattern shows a dustpan core (Fig. 3b), which can be used to initially determine the fingerprint type and ridge orientation. The secondary pattern reflects the resolution of fingerprint ridges, including bifurcations (Fig. 3c), ridge ends (Fig. 3d) and bridges (Fig. 3e), which are defined as small dots and are mainly used for personal identification. More intriguingly, the latent fingerprints using magnetic fluorescent nanoparticles can clearly show the level 3 pattern with islands (Fig. 3f) and display more complex detail points and additional personal characteristics, which is highly beneficial to improve the reliability and accuracy of identifying latent fingerprints in the analysis.

Figure  3.  Detailed characteristic images of fingerprints developed by NaGdF₄:Yb,Er-Fe₃O₄ nanomaterials under a 980 nm infrared laser on metal substrates. (a) Complete fingerprint without IR light, (b) dustpan, (c) bifurcation, (d) ridge ends, (e) bridges and (f) islands.

DownLoad: Full-Size Img PowerPoint

To further demonstrate the advantages of NaGdF₄:Yb,Er-Fe₃O₄ in practical applications, we compared the development of latent fingerprints on two surfaces with dark complex backgrounds from magnetic powders, fluorescent powder and the composites. The results show that the fingerprint patterns using the NaGdF₄:Yb,Er-Fe₃O₄ composite material (Fig. S7) have high contrast and high resolution, and relatively fine structures can still be observed. In contrast, only low-contrast gray fingerprints were developed using magnetic powder, and structures were difficult to identify on dark backgrounds. In general, the composite material integrates the advantages of magnetic powder and fluorescent powder, greatly improving the resolution and contrast of fingerprints under the premise of nondestructive construction of fingerprints.

To evaluate the universality of the as-developed NaGdF₄:Yb,Er-Fe₃O₄ latent fingerprints under 980 nm infrared irradiation, fingerprints were created simultaneously on various permeable and impermeable substrates. High-resolution photographs of fingerprints (Fig. 4) indicate that the synthetic magnetic phosphor has excellent adherence to fingerprint ridges on impervious surfaces (e.g., metal, glass, ceramic and acrylic); smooth-surfaced impermeable substrates (e.g., bank cards, nail clippers, mobile phone screens and tin foil); and permeable substrates (e.g., A4 paper, envelopes, vouchers and playing cards). All these results demonstrate the versatility of bifunctional nanomaterials for latent fingerprint detection applications.

Figure  4.  Photographs of latent fingerprints developed by NaGdF₄:Yb,Er-Fe₃O₄ on various substrates. (a) Metal, (b) glass, (c) ceramic, (d) acrylic, (e) bank card, (f) nail clipper, (g) mobile phone screen, (h) tin foil, (i) A4 paper, (j) envelope, (k) voucher and (l) playing card.

DownLoad: Full-Size Img PowerPoint

4.   Conclusions

In conclusion, we developed a NaGdF₄:Yb,Er-Fe₃O₄ upconversion-magnetic composite structure using a ligand-linked method and investigated its resolution as a latent fingerprint visualizer. The NaGdF₄:Yb,Er-Fe₃O₄ composite exhibits outstanding adherence on fingerprint ridges toward developing fingerprints and realizing the most basic latent fingerprint visualization material function. Multiple sets of fingerprints generated on permeable and impermeable substrates demonstrate that NaGdF₄:Yb,Er-Fe₃O₄ can cope with a wide range of material substrates. Compared to commercial magnetic powders, the fingerprints generated by NaGdF₄:Yb,Er-Fe₃O₄ on substrates with dark and complex backgrounds had superior identification and resolution. When partially obscured by dark text or lines, commercial magnetic powder fingerprints are barely detectable, indicating the truncated essence of the fingerprints. In contrast, our NaGdF₄:Yb,Er-Fe₃O₄ fingerprints are virtually detectable, showcasing the continuous nature of the fingerprints. Our developed NaGdF₄:Yb,Er-Fe₃O₄ composite nanomaterials have excellent resolution and a broad application in latent fingerprint development, as well as the ability to cope with dark and complex background substrates, making them promising as latent fingerprint developers with broad application prospects.

Conflict of interest

The authors declare that they have no conflict of interest.
